Arducam IMX219 Visible Light Fixed Focus Camera Module for NVIDIA® Jetson AGX Orin/Orin Nano/Orin NX

More Than HD: This camera adopts 1/4” 8 Megapixel IMX219 sensor for sharp image, Max. still resolution is 3280 x 2464 pixels.
Focal Length: 3.04 mm; Angle of View: H=62.2 degree, V=48.8 degree
IR Sensitivity: Integral IR filter, visible light only

SKU: B0191 Categories: 8MP IMX219, Embedded Camera Module, Native Camera, NVIDIA Jetson Tags: imx219, jetson nano

Description
Additional information

Description

Overview

This Arducam IMX219 camera module is designed mainly for the Nvidia Jetson platform and also can be used on other hardware like ARM, DSP, FPGA, etc.

Currently, NVIDIA official has released the NVIDIA Jetson Orin series developer board. Based on it, we have also adapted the camera into NVIDIA Jetson Orin kernel.

★KERNEL CAMERA DRIVER USED

This camera relies on kernel drivers to work – one kernel version, one camera driver. Please refer to the Supported JetPack Version for Different NVIDIA Jetson Platforms to ensure compatibility.

★ SUPPORTED PLATFORM DISCLAIMER

This camera is specifically designed for the official NVIDIA® Jetson™ Developer Kit by default and does not support third-party carrier boards.

Application:

Unmanned Aerial Vehicles (UAVs)
Building Drones
Autonomous Robotic Systems
Mobile Medical Imaging
Intelligent Video Analytics (IVA)

Features:

Sony 8MP IMX219 Sensor
Optical Format: 1/4 inch
EFL: 3.04mm
F.NO: 2.0
Focus Type: Fixed Focus
View Angle: 62.2 (Diagonal)
Interface: MIPI CSI-2 2-lane
Focus distance: 200mm ~ infinity

Specifications

Camera

Image Sensor	IMX219
Still Resolution	8 Megapixels
Video Modes	NVIDIA Jetson Orin NX/Orin Nano/AGX Orin: 3280x2464@21fps, 3280x1848@28fps, 1920x1080@30fps, 1640x1232@30fps, 1280x720@60fps
Sensor Resolution	3280 × 2464 pixels
Sensor image area	3.68 x 2.76 mm (4.6 mm diagonal)
Pixel Size	1.12 µm x 1.12 µm
Optical Size	1/4"
IR Sensitivity	Integral IR-cut Filter, visible light only

Lens

Focus Type	Fixed Focus
Focal Length	3.04mm
F.NO	F2.0
Field of View(FOV)	62.2°(H)×48.8°(V)
Lens Type	Stock Lens
Focus Distance	200mm to infinity

Electrical & Mechanical

Camera Board Size	25 × 24mm
Peaking Current	300mA

Package Including:

1pcs Arducam IMX219 Visible Light Fixed Focus Camera Module
1pcs 15cm 15-22pin FPC cable
1pcs 15cm 22-22pin FPC cable

Documentation:

How to use the camera on NVIDIA Jetson Orin NX/AGX Orin
How to use the camera on Jetson
IMX219 – 8MP Camera
Posted: August 6, 2020
Introduction IMX219 is a 1/4″ 8MP MIPI CSI-2 image sensor, it was adopted by the Raspberry pi V2 camera module back in 2016. Now the IMX219 camera is natively supported by the Jetson Nano and Xavier NX out of the box. Arducam made a lot of variation of this camera to address different use-cases for […]
0 comments

Datasheet.pdf

Blog

Arducam Introduces 8MP IMX219 Auto Focus, Wide Angle, Zero-Distortion and Spy Camera to the NVidia Jetson Nano

Posted: June 25, 2019

NVIDIA JETSON NANO AND ITS CAMERAS The Jetson Nano is a powerful single-board computer from NVidia. Featuring the extraordinary GPU performance, this NVidia development board is widely used in image processing applications like motion-tracking, face recognition and home surveillance camera systems, and a smart camera is a key to realizing all of them. However, currently, […]

2 comments

Video

GitHub

ArduCAM/Nvidia_Jetson

How to purchase

You can purchase this item from Arducam distributors

Additional information

Platform	NVIDIA Jetson
Camera Solution	Native Camera
Interface	MIPI CSI
Sensor	IMX219
On-board ISP	NO
Shutter Type	Rolling Shutter
Resolution	8MP
Chroma	Color
Features	High Speed
Focus Type	Fixed Focus
